Specifications :
CNC : FANUC 0i MC
Table surface 1000 x 500 mm
X Stroke 850 mm
Y Stroke 510 mm
Z Stroke 540 mm
Max. Table load 500 kg
Spindle speeds 2 – 8 000 RPM
Spindle power 11 KW
Spindle taper BT 40
Rapids 18 m/min
Approx. dimensions 2850 x 2355 x H 2950 mm
Approx. weight 6300 kg
Equipped with :
24 ATC
8.000 RPM Spindle
Swarf Conveyor
