Specifications :

Max. drilling diameter    50 mm (steel)

Max. drilling diameter   60 mm (cast iron)

Arm vertical stroke   875 mm

Arm orientation on column  0° to 180°

Min. / max. distance between spindle and  base   320 / 1 505 mm

Min. / max. distance between spindle axis and column guiding  320 / 1 600 mm

Min. / max. circle of holes to drill  1 208 / 3 735 mm

Spindle stroke   310 mm

Spindle taper  No  5 MT

Spindle diameter  55 mm

Spindle speed  (16 ranges)   28 – 2 500 RPM

Spindle feed rates (16 ranges)   0,05 – 2 mm/rev

Useful area of base   1 145 x 3 100 mm

Machine height  3 396 mm

Machine weight   4 300 kg
